Garden Pump  (JDP-P)

Basic Info

Model NO.	JDP-P
Max.Capacity	<50 L/min
Driving Type	Motor
Material	Plastic
Structure	Single-stage Pump
Assembly	Booster Pump
Power	Electric
Start Up	Electric Pump
Type	Submersible Pump
Application	Submersible Pump
Industry	Water Pump
Media	Powder Pump
Performance	Explosion-Proof Pumps
Theory	Rotary Pump
Transport Package	Carton or Wooden Cases
Specification	460*340*330/460*340*360
Trademark	JT
Origin	China
HS Code	8413
Production Capacity	50, 000 PCS/Year

Packaging & Delivery

Package size per unit product 45.00cm * 38.00cm * 30.00cm Gross weight per unit product 25.000kg

Product Description

Operating limits:

1. Fluid temperature up to 35
2. Maximum ambient temperature 40
3. Max particale: 5mm(clean water).

220V/50Hz, 230V/50Hz, 110V/60Hz & 115V/60Hz models are available on request.

MODEL	INPUT POWER	VOLTAGE	MAX. FLOW	MAX. HEAD	MAX. DEPTH	DIA. OF PIPE	LENGTH OF CABLE	PACKING DIMENSION	MEASUREMENT	WEIGHT APPROX
JDP-200P	200W	230V/50Hz	5000L/h	5.4m	5m	1-1/2"	10m	22x16x31cm	46x34x33cm	15.5kg/17kg
JDP-250P	250W	230V/50Hz	5500L/h	6m	5m	1-1/2"	10m	22x16x31cm	46x34x33cm	15.5kg/17kg
JDP-350P	350W	230V/50Hz	6200L/h	7m	5m	1-1/2"	10m	22x16x31cm	46x34x33cm	16.5kg/18kg
JDP-400P	400W	230V/50Hz	7300L/h	7.5m	7m	1-1/2"	10m	22x16x31cm	46x34x33cm	16.5kg/18kg
JDP-550P	550W	230V/50Hz	11500L/h	8.5m	8m	1-1/2"	10m	22x16x31cm	46x34x33cm	17kg/19kg
JDP-750P	750W	230V/50Hz	13000L/h	9.5m	8m	1-1/2"	10m	22x16x34cm	46x34x36cm	19kg/21kg
JDP-900P	900W	230V/50Hz	15000L/h	10m	8m	1-1/2"	10m	22x16x34cm	46x34x36cm	20.5kg/22kg
